Video
  • Powder Coating Equipment Spray Booth with Filter Recovery System COLO-2315.pdf Powder Coating Equipment Spray Booth with Filter Recovery System COLO-2315.pdf
  • Description

Powder Coating Equipment Spray Booth with Filter Recovery System


Excellent Features

1. Simple and economic solution for small metal powder coating application in batch production

2. Compact Modular design, easy to intergrated every time.

3. Maximum utilization of powder, 98% high levels of powder recovery.

4. Convenient to use with manual powder coating machine and curing oven.

5.The 4 pcs filter recovery system prevents accumulation of the powder and makes it very easy for cleaning and fast color change.

6. Durable, long-life powder-coated steel structure with high-quality galvanized canopy and floor


Promotion Now!

powder coating recovery booth


Filter Recovery Powder Coating Booth Application:


All kinds of metal parts: car wheels, bicycle frames, motorcycle parts, furniture(chairs, shoe racks, cabins), iron art parts(lamp shade, candle holder, decorative products)

powder coating booth for sale


Manual Powder Coating Spray Booth Specifications


Model Colo-2315
Power Supply AC 380V (can be customized)
Frequency 50-60 HZ
Power Consumption 4KW
Air Comsumption 6677-13353m3/h
Filters Polyester
Filter Count 4(325*900mm)
Filter Cleaning System pneumatic
Machine Weight 450kg
Operation Szie Width2300*Depth1500*Height1500mm
Overall Size Width2750*Depth2070*Height2180mm


CL-2315 Powder Coating Booth Components


filter powder coating booth 100% Polyester filters
Colo's booths uses only the highest quality filters made from 100% polyester, they does not sink water, well separates the powder from the air. They can be washed with water under pressure, they provide long-term operation.


powder coating booth Fans
In Booths manufactured by Colo we use aluminium fans which are safe, doesn't cause sparks when rubbing by metal elements which in case of using metal fan can cause explode. Because of their importance to save energy and consume small amounts of current. And they are very quiet, work at the level of 74-79dB. The motor is hidden in the Booth, which makes the Booth lower.


powder coating spray booth Automatic filter cleaning
Colo's cabins are equipped with an electronic automatic filter cleaning system. Booth has a adjusted range of cleaning interval, the time of the impulse, each filter is individually cleaned, filters can also be cleaned manually with buttons.


manual powder coating booth PLC Control unit
Colo’s control unit have many program. Different bottom correspondence different function. Control the fan on/off, adjust time range of the pulse to cleaning filters, make the recovery powder hopper up and down.



Different size powder coating booth can be customized, contact us!
